WideTEK® 44

WideTEK® 44

The WideTEK 44 CCD scanner scans documents up to 44 inches wide (1118 mm) astonishingly fast and is easi-ly upgradable to a 48 inch scanner. Bright white LED illumi- nation ensures long lifetime and best scan results. WideTEK 44 gently scans due to special transport rollers that serve as pressure points for safe document transport. The new background drum protects the glass plate from scrat- ches and stops document skew. For extra contrast on sepias and fi lm based documents, the black drum can easily be exchanged with a white drum, with no tools required.

• Face up scanning with on the fl y rotation and modifi cation of images without rescanning. Automated crop & deskew.

• For high resolution scans up to 44 inches (1118 mm) in width, 1200 x 1200 dpi scanner resolution

• Real time display of images and modifi cation, no rescanning

• Fastest color scanning, 11.2 inches per second at 200 dpi

• Touchscreen enhanced versions of ScanWizard, PrintWizard and EasyScan

• Scan2USB for walk up scanning to USB 3.0, Scan2Print for output to any connected printer, Scan2Network for output to any network drive, Scan2FTP, Scan2Mail

• Large 22" full HD color touchscreen for simplified operation in optional bundles

• Standalone device with its own integrated computer

• Easy installation via Scan2Net® technology


Scanner Optics CCD camera, scans in color, grayscale, B&W

Resolution 1200 x 1200 dpi scanner resolution 1200 x 600 dpi optical resolution 9600 x 9600 dpi interpolated (optional)

Document Size 1270 mm (50 inch width), nearly unlimited length in endless mode. Scans 1118 mm (44 inch) widths.

Scanning Speed 200 dpi – 17 m/min (11.2 inch/s) 600 dpi – 4,6 m/min (3 inch/s) Color Depth 48 bit color, 16 bit grayscale

Scan output 24 bit color, 8 bit grayscale, bitonal, enhanced half- tone

Output Formats Multipage PDF (PDF/A) and TIFF, JPEG, JPEG 2000, PNM, PNG, BMP, TIFF (Raw, G3, G4, LZW, JPEG), AutoCAD DWF, JBIG, DjVu, DICOM, PCX, Postscript, EPS, Raw data

Size H x W x D & Weight 228 x 1425 x 507 mm (9 x 56.1 x 20 inch) 53 kg (117 lbs.)

Quality (min.) ISO 19264-1 level B, FADGI ***, Metamorfoze

Power Consumption < 0.5 W (Sleep) / 6.5 W (Standby) / < 60 W (Ready to scan) / < 120 W (Scanning)
